MEP TOOLS

Description

Common Tools (Included in all versions)

• View & Template: Bulk duplicate views and easily import/export templates between projects.
• Sheet Automation: Batch-create sheets from Excel, auto-renumber, and manage sheet organization.
• Family Placement: Automatically place families onto CAD blocks, native, or linked ceilings.
• Selection & Filtering: Isolate elements via custom rules, group by level, and auto-generate V/G filters.
• Clash Coordination: Sync Navisworks reports or review internal clashes with direct 3D jump-to-clash navigation.
• Annotation & Data: Automate element marking, sync parameters, batch-tag, and clean up schematic line crosses.

MEP Tools (Exclusive)

• Routing & Automation: Model parallel pipes/conduits with spacing, convert 2D CAD lines to 3D pipes, and automate flexible transitions.
• Crossing Engine: Instantly bypass obstacles using 4 custom vertical routing methods (Single or Multi-elements).
• MEP Alignment & Connections: Match elevations/horizontal spacing, align systems in 3D, and connect branches at 45°/90° angles without leaving 3D views.
• MEP Assistant Utilities: Fix “Undefined” system type bugs, auto-add flanges/accessories to open ends, control pipe spacing, and access rapid Edit tools (Rotate/Extend/Elbow/Disconnect).
